2QuickStartup
APCD-LM043-4.0 7
2.3 CCU Configuration
1. Start the PC terminal emulation software. You will receive the following prompt:
WaveRider Communications, Inc. LMS3000
Password:
The default password is a carriage return.
Console>
The default prompt on your CCU is the CCU Ethernet MAC address.
2. Type the following commands to configure the CCU:
Console> ip ethernet 192.168.10.10 24
Console> ip radio 10.0.0.1 22
Console> ip gateway 192.168.10.1
Console> radio frequency 9150
Console>
Console> save
Basic Config saved
Port Filter Config saved
sntp cfg file saved
Route Config saved
Authorization Database saved
DHCP Server Config saved
3. Reboot the CCU for the changes to take effect.
Console> reset
rebooting CCU ...
(... Power On Self Test ...)
WaveRider Communications, Inc. LMS3000
Password:
TIP: If you want to connect the Quick Setup to the Internet as
outlined in Connecting the Quick Startup to the Internet on page
11, obtain the CCU gateway IP address from your network
administrator. You can then set the CCU Ethernet IP address to
any IP address in the subnet.
4. Confirm the CCU has been properly configured, as follows:
Console> ip
Ethernet IP Address: 192.168.10.10
Ethernet Net Mask : ffffff00
Gateway IP Address: 192.168.10.1
Radio IP Address: 10.0.0.1
Radio Net Mask : fffffc00
Console> radio
RF Power: HIGH
Radio Frequency: 9150
Console>
