rxPktsEmpty
3
Number of packets received that are directed
to this station, but that did not contain a
payload.
txPkts
3
Number of packets transmitted.
txPktsEmpty
3
Number of packets transmitted with no
payload.
txPayloads
3
Number of payloads transmitted.
txPayloadsBCast
3
Number of broadcast payloads transmitted.
[CCU only]
txPayloads1Ok
3
Number of payloads acknowledged after the
first transmission.
txPayloads2Ok
3
Number of payloads acknowledged after the
second transmission.
txPayloads3Ok
3
Number of payloads acknowledged after the
third transmission.
txPayloads4Ok
3
Number of payloads acknowledged after the
fourth transmission.
txPayloadsFailRetry
3
Number of payloads that failed to transmit due
to the retry limit.
txPayloadsFailAssocDeleted
3
Number of payloads that were discarded
because the EUM was unreachable or
deauthorized. [CCU only]
txPayloadsFailBadParam
3
Number of payloads returned to the host
because they are improperly formed (internal
error).
txPayloadsFailVnetInactive
3
Number of payloads returned to the host
because the virtual net was not active (internal
error). [CCU only]
txPayloadsFailAssocFail
3
Number of payloads returned to the host
because too many other EUMs were already
associated.[CCUonly]
txPayloadsFailTimeout
3
Number of payloads returned to the host
because of timeout.
txPayloadsFailQueueTooLong
3
Number of payloads returned to the host
because the transmit queue for the EUM was
too long (see note 4). [CCU only]
txPayloadsEmpty Not used.
Statistic
Available
in MIB
Description (see note 2)
