APCD-LM043-4.0 227
To view the radio driver statistics:
CCU> stats ra
------------------- Radio Driver Statistics ---------------------
Events : 376194
Rx Complete Event : 184886
Tx Complete Event : 189052
Cmd Complete Event : 0
FATAL ERROR Event : 0
Tx Power Rail Event : 0
Unknown Event : 2348
Send : 189143
Send Q Full : 0
Send MBlk Unavailable : 0
Send Not Enabled : 0
AMM Put : 189143
AMM Q Full : 0
AMM Q Full Discard : 0
AMM get : 184886
AMM Q Empty : 99
Receive : 184886
Receive MBlk Unavailable : 0
Receive Not Enabled : 0
CCU>
AMM Q Full Discard
3
Number of times a packet was discarded due
to the MAC-layer shared memory transmit
queue not draining.
AMM Get
3
Number of packets received from the MAC-
layer shared memory.
AMM Q Empty
3
Number of times there was a receive interrupt,
but nothing available to read out of the MAC-
layer shared memory.
Receive
3
Number of successfully received packets.
Receive MBlk Unavailable
3
Number of times the radio driver could not
allocate an mblk (memory block) for storing a
packet retrieved from the MAC-layer shared
memory.
Receive Not Enabled
3
Number of times the radio driver received a
receive interrupt, but the radio driver was not
yet up and running. The received packet is
ignored in this case.
Statistic
Available
in MIB
Description
