APCD-LM043-4.0 225
To view the Ethernet statistics:
CCU> stats ethernet
-------------------- Ethernet Statistics -----------------------
Interrupts : 288647
RX Interrupts : 151103
RX Overrun Interrupts : 0
RX In Progress Interrupts : 4676
TX Complete Interrupts : 133189
TX Error Interrupts : 0
TX Carrier Lost Interrupts : 0
TX Alloc Interrupts : 0
TX EPH Interrupts : 0
TX ERCV Interrupts : 0
RX Data : 158095
RX Data Error : 0
RX Data Mblk Alloc Error : 0
RX Data Length Error : 0
RX Discards (No Space Available) : 18
TX Data : 133189
TX Data Q Full : 0
TX'D OK : 133189
TX Timeout : 0
TX Sem Wait : 0
CCU>
RX Data
3
Number of packets received and accepted by
the IP stack.
RX Data Error
3
Number of packets received and rejected by
the IP stack because of errors.
RX Data Mblk Error
3
Number of packets lost due to insufficient
memory resources.
RX Data Length Error
3
Number of packets received that violate
Ethernet packet length rules.
RX Discards
3
Number of packets discarded because the unit
was not ready to receive data.
TX Data
3
Number of packets received and placed on the
transmit queue.
TX Data Q Full
3
Number of packets discarded because the
transmit queue was full.
TX’D OK
3
Number of packets sent correctly.
TX Timeout
3
Number of times the packet transmit has timed
out.
TX Sem Wait
3
Number of times a transmit semaphore could
not be taken in the timeout period.
Statistic
Available
in MIB
Description
