224 APCD-LM043-4.0
To Display (all) Statistics from the CLI
• At the command prompt, type stats and press Enter.
The following sections describe each of the statistics in detail and the procedure for obtaining
specific sets of statistics (Ethernet, Radio, and so on).
Ethernet Statistics
Ethernet Statistics present operational information about data passing through the CCU and
EUM Ethernet ports. These statistics are described in Table 85.
As indicated in Ta ble 85, all of the Ethernet statistics are available in a WaveRider MIB.
Table 85 Ethernet Statistics
Statistic
Available
in MIB
Description
Interrupts
3
Total number of interrupts received by the
Ethernet driver ISR, interrupt service routine.
RX Interrupts
3
Number of receive complete interrupts
received by the Ethernet driver ISR.
RX Overrun Interrupts
3
Number of overrun interrupts received by the
Ethernet driver ISR. An overrun occurs when a
received packet has exceeded the packet
size, or the processor has missed one or more
packets.
RX In Progress Interrupts
3
Number of times a receive complete interrupt
was received by the Ethernet driver ISR
before the current packet was finished.
TX Complete Interrupts
3
Number of normal transmit interrupts received
by the Ethernet driver ISR.
TX Error Interrupts
3
Number of transmit error interrupts received
by the Ethernet driver ISR.
TX Carrier Lost Interrupts
3
Number of transmit carrier lost interrupts
received by the Ethernet driver ISR.
TX Alloc Interrupts
3
Number of transmit allocation complete
interrupts received by the Ethernet driver ISR.
TX EPH Interrupts
3
Number of transmit EPH interrupts (Ethernet
protocol handler interrupts) received by the
Ethernet driver ISR.
TX ERCV Interrupts
3
Number of transmit ERCV interrupts (early
receive interrupts) received by the Ethernet
driver ISR.
