Notes:
•Apacket is the basic unit of transmission. A packet may or may not contain a payload.
A payload is user data, which may be an Ethernet frame or a logical link layer control
message.
• WEP is not supported in this release.
• Registration occurs once per EUM and/or CCU boot time. Deregistration may occur if
an EUM is not authorized (a registration/deregistration request pair occurs periodically
while that EUM is powered ON) or if the EUM does not respond to multiple
consecutive polls, such as when it is powered OFF.
• Association occurs when there is traffic to send to or from an EUM. Disassociation
occurs if there is no traffic to or from an EUM for a short period of time.
EUM Ethernet Statistics Group
All EUM Ethernet Statistics Group MIB values are read only. All values in Table 83 are prefixed
with 1.3.6.1.4.1.2979.12.4.
Table 83 WaveRider CCU Ethernet Statistics Group MIB
eumRadioMACReplyOrRssiTimeout 48 Counter Number of times the RSSI timer expired because the
EUM had not received anything from the CCU for
more than 0.5s.
eumRadioMACRestarts 49 Counter Number of times that the MAC layer recovered from
an internal error or unexpected event.
eumRadioMACRegRequests 50 Counter Number of registration requests transmitted (see note
4).
eumRadioMACRegResponse 51 Counter Number of registration responses received (see note
4).
eumRadioMACDeregRequests 52 Counter Number of deregistration requests received (see note
4).
53 Not used. Returns a value of ‘0’.
eumRadioMACDisassociationRequests 54 Counter Number of disassociation requests received (see note
5).
55 r Not used. Returns a value of ‘0’.
MIB Name OID
Value
Type
Description
MIB Name OID
Value
Type
Description
eumEtherInterrupts 1 Counter Total number of interrupts received by the Ethernet
driver ISR, interrupt service routine.
eumEtherRxInterrupt 2 Counter Number of
receive complete interrupts received by the
Ethernet driver ISR.
