218 APCD-LM043-4.0
eumRadioMACRxPktsHCRCFail 24 Counter Number of packets received with a MAC header CRC
failure (header corrupted).
eumRadioMACRxPktsICVFail 25 Counter Number of packets received with an encryption (WEP,
wireless equivalent privacy) key mismatch (see note
3).
eumRadioMACRxPktsFCSFail 26 Counter Number of packets received with a Frame Check
Sequence failure (payload corrupted).
27 Not used. Returns a value of ‘0’.
eumRadioMACRxPktsIncomplete 28 Counter Number of times the receive DMA for a payload does
not complete (internal error).
eumRadioMACRxPayloadsFailFull 29 Counter Number of times a received payload has to be
discarded because either no receive descriptor was
available, or there was not enough buffer space.
eumRadioMACRxPayloadsDelivered 30 Counter Number of payloads that this station received
correctly.
eumRadioMACRxPktsEmpty 31 Counter Number of packets received with no payload.
eumRadioMACTxPkts 32 Counter Number of packets transmitted.
eumRadioMACTxPktsEmpty 33 Counter Number of packets transmitted with no payload.
eumRadioMACTxPayloads 34 Counter Number of payloads transmitted.
35 Not used. Returns a value of ‘0’.
eumRadioMACTxPayloads1Ok 36 Counter Number of payloads acknowledged after the first
transmission.
eumRadioMACTxPayloads2Ok 37 Counter Number of payloads acknowledged after the second
transmission.
eumRadioMACTxPayloads3Ok 38 Counter Number of payloads acknowledged after the third
transmission.
eumRadioMACTxPayloads4Ok 39 Counter Number of payloads acknowledged after the fourth
transmission.
eumRadioMACTxPayloadsFailRetry 40 Counter Number of payloads that failed to transmit due to the
retry limit.
41 Not used. Returns a value of ‘0’.
eumRadioMACTxPayloadsBadParam 42 Counter Number of payloads returned to the host because
they are improperly formed (internal error).
43 Not used. Returns a value of ‘0’.
44 Not used. Returns a value of ‘0’.
eumRadioMACTxPayloadsTimeout 45 Counter Number of payloads returned to the host because of
timeout.
46 Not used. Returns a value of ‘0’.
47 Not used. Returns a value of ‘0’
MIB Name OID
Value
Type
Description
