APCD-LM043-4.0 217
eumRadioMACRxPayloadFailInvalidType 3 Counter Number of times an unknown type of payload was
received from the air interface.
eumRadioMACRxPayloadFailGiant 4 Counter Number of times a payload that was too long was
received from the air interface, and therefore
discarded.
eumRadioMACNullRxDesc 5 Counter Number of times the internal MAC receive interface
was corrupted.
eumRadioMACTxDataPayloads 6 Counter Number of Ethernet frames transmitted to the air
interface.
eumRadioMACTxCtrlPayloads 7 Counter Number of control payloads transmitted to the air
interface.
eumRadioMACTxPayloadFailInvalidType 8 Counter Number of times a payload of an unknown type was
discarded.
eumRadioMACTxPayloadFailGiant 9 Counter Number of times a payload that was too long was
discarded.
ccRadioMACTxPayloadFailInvalidDesc 10 Counter Number of times the internal MAC transmit interface
was corrupted.
eumRadioMACTxBufferFullOnArrival 11 Counter Number of transmit packets that were queued for
delivery.
eumRadioMACCmdTimeOuts 12 Counter Number of times the MAC-layer management
message was incomplete.
eumRadioMACCmdMissedIRQs 13 Counter Number of times there was no response to the MAC-
layer management message.
eumRadioMACFalseCmdIRQs 14 Counter Number of times a hardware IRQ was detected with
no message associated. This MIB parameter is used
primarily by software development.
eumRadioMACCmdStatusErrors 15 Counter Number of times the MAC-layer management
message was rejected.
eumRadioMACFatalError 16 Counter Number of nonrecoverable MAC-layer errors, each
requiring an EUM reboot.
17 Reserved.
eumRadioMACRxPacketsRedirected 18 Counter Number of times a poll for the EUM is received from
the CCU with the correct HCRC.
eumRadioMACRxPktsBroadcast 19 Counter Number of broadcast packets (see note 1) received
with the correct HCRC.
eumRadioMACRxPktsNoMatch 20 Counter Number of packets correctly received, but not directed
to, this station.
eumRadioMACRxPktsDuplicate 21 Counter Number of duplicate payloads (see note 1) received
and discarded. Indicates that a MAC layer
acknowledgement was lost.
eumRadioMACRxPktsRuntFail 22 Counter Number of packets received that were shorter than
the minimum size.
eumRadioMACRxPktsLongFail 23 Counter Number of packets received that were longer than the
maximum size.
MIB Name OID
Value
Type
Description
