216 APCD-LM043-4.0
EUM Radio MAC Statistics Group
All EUM Radio MAC Statistics Group MIB values are read only. All values in Table 82 are
prefixed with 1.3.6.1.4.1.2979.12.3.3.
Table 82 WaveRider EUM Radio MAC Statistics Group MIB
eumRadioDrvUnknownEvent 7 Counter Number of received an unknown/no event interrupts
received by the radio driver ISR.
eumRadioDrvSend 8 Counter Number of packets sent successfully by the radio driver
transmit queue.
eumRadioDrvSendQFull 9 Counter Number of packets not sent because the radio driver
transmit queue was full.
eumRadioDrvSendUnavailable 10 Counter Number of times invalid (null) mblks were sent to the radio
driver for transmission.
eumRadioDrvSendNotEnabled 11 Counter Number of times tried to send packets before the radio
driver was started; i.e., before the device was up and
working.
eumRadioDrvAMMPut 12 Counter Number of times a packet was successfully sent to the
MAC-layer shared memory for transmission over the air.
eumRadioDrvAMMQFull 13 Counter Number of times a packet could not be sent to the MAC-
layer shared memory because there were no transmit
descriptors left. Radio driver tries 5 more times to send the
packet.
eumRadioDrvAMMQFullDiscard 14 Counter Number of times, after 5 attempts, a packet could not be
sent to the MAC-layer shared memory because there were
no transmit descriptors left. Packet is discarded.
eumRadioDrvGet 15 Counter Number of packets received from the MAC-layer shared
memory.
eumRadioDrvQEmpty 16 Counter Number of times there was a receive interrupt, but nothing
available to read out of the MAC-layer shared memory.
eumRadioDrvRx 17 Counter Number of successfully received packets.
eumRadioDrvRxNotAvailable 18 Counter Number of times the radio driver could not allocate an
mblk (memory block) for storing a packet retrieved from
the MAC-layer shared memory.
eumRadioDrvRxNotEnabled 19 Counter Number of times the radio driver received a receive
interrupt, but the radio driver was not yet up and running.
The received packet is ignored in this case.
MIB Name OID Value Type Description
MIB Name OID
Value
Type
Description
eumRadioMACRxDataPayloads 1 Counter Number of Ethernet frames received correctly from
the air interface.
eumRadioMACRxCtrlPayloads 2 Counter Number of control payloads received correctly from
the air interface.
