APCD-LM043-4.0 215
EUM Radio Statistics Group
All EUM Radio Statistics Group MIB values are read only. All values in Table 79 are prefixed
with 1.3.6.1.4.1.2979.12.3.
Table 79 WaveRider EUM Radio Statistics MIB
EUM Radio General Statistics Group
All EUM Radio General Statistics Group MIB values are read only. All values in Ta ble 80 are
prefixed with 1.3.6.1.4.1.2979.12.3.1.
Table 80 WaveRider EUM Radio General Statistics Group MIB
EUM Radio Driver Statistics Group
All EUM Radio Driver Statistics Group MIB values are read only. All values in Table 81 are
prefixed with 1.3.6.1.4.1.2979.12.3.2.
Table 81 WaveRider EUM Radio Driver Statistics Group MIB
MIB Name OID
Value
Type
Description
eumRadioStatsGeneral 1 MIB General radio statistics.
eumRadioStatsDriver 2 MIB Radio driver statistics
eumRadioStatsMAC 3 MIB Radio MAC statistics.
MIB Name OID Value Type Description
eumRadioGenRSSI 1 Integer Radio receive signal strength indicator, in dBm. ‘0’
indicates no signal present.
MIB Name OID Value Type Description
eumRadioDrvEvents 1 Counter Number of interrupts received (any interrupt) in the radio
driver ISR (Interrupt Service Routine)
eumRadioDrvRxComplete 2 Counter Number of
receive complete interrupts received by the
radio driver ISR.
eumRadioDrvTxComplete 3 Counter Number of
transmit complete interrupts received by the
radio driver ISR.
eumRadioDrvCmdComplete 4 Counter Number of
command complete interrupts received by the
radio driver ISR.
eumRadioDrvFatalEvent 5 Counter Number of
fatal error interrupts received by the radio
driver ISR.
eumRadioDrvTxPowerRailEvent 6 Counter Number of
Tx Power alarm interrupts received by the radio
driver ISR.
