EUM General Information Group
All values in Table 77 are prefixed with 1.3.6.1.4.1.2979.12.1.
Table 77 WaveRider EUM General Information Enterprise MIBs
EUM Radio Configuration Group
All EUM Radio Configuration Group MIB values are read only. All values in Table 78 are
prefixed with 1.3.6.1.4.1.2979.12.2.
Table 78 WaveRider EUM Radio Configuration Enterprise MIBs
MIB Name OID Value Type Status
Accepted
Values
Description
eumSerialNumber 1 String R EUM hardware serial number
eumSoftwareVersion 2 String R EUM firmware version.
eumHardwareVersion 3 String R EUM hardware version.
eumExtraFunctions 4 Integer R 0 A mask for extra functionality that may
be added at a later date. For now, it
returns ‘0’.
eumGlobalStatus 5 Integer R 1: startup
2: dead
3: ok
4: suspect
Current status of the radio interface.
For now, this field returns ‘ok’.
eumGlobalSaveCounter 6 Counter R A count of the number of times the
configuration is saved. Initially, this field
always returns ‘0’.
eumGlobalConfigFiles 7 String R A list of configuration files for the EUM.
The list is delimited with a semicolon;
i.e., “basic.cfg;route.cfg, ...”
eumGlobalReset 8 Integer W 1: reset Not functional at this time.
eumGlobalReload 9 Integer W 1: reload Not functional at this time.
MIB Name OID
Value
Type
Accepted
Values
Description
eumRadioConfigVersion 1 String Radio firmware version.
eumRadioConfigMacAirlinkAddr 2 Phys
Address
MAC address Radio MAC address.
eumRadioConfigFrequency 3 Integer Radio frequency in use (in 1/10ths of a
MHz)
eumRadioConfigDomain 4 Integer 0: IEEE
1: FCC or IC/
Canada
Current regulatory domain for which the
radio is configured.
eumRadioHardwareRevision 5 String Radio hardware revision.
