APCD-LM043-4.0 213
WaveRider EUM Enterprise MIBs
The structure of the EUM MIBs is illustrated in Figure 52.
Figure 52 EUM MIBs
Each of the MIBs in Figure 52 is discussed in the following sections.
EUM Base MIB
All values in Table 76, which are read only, are prefixed with 1. 3. 6.1.4.1. 2979.12.
Table 76 WaveRider EUM Base MIB
MIB Name OID Value Type Description
eumGlobal 1 MIB EUM general data.
eumRadioConfig 2 MIB EUM configuration and setup data.
eumRadioStats 3 MIB EUM radio statistics.
eumEtherStats 4 MIB EUM Ethernet statistics
eumModems 5 MIB EUM registration and authorization information.
WaveRider (2979)
waverider
eumGlobal
eum3000pmacglob
eumRadioConfig
eum3000pmacradcfg
eumRadioStats
eum3000pmacrs
eumEtherStats
eum3000pmaces
eumRadioStatsGeneral
eum3000pmacrsgen
eumRadioStatsDriver
eum3000pmacrsdrv
eumRadioStatsAtmel
eum3000pmacrsatmel
Enterprise (1.3.6.1.4.1)
LMS3000 EUM
eum3000pmac
MIB Name
MIB File Prefix
Legend
