212 APCD-LM043-4.0
CCU Authorization Information MIB
All CCU Authorization MIB values are read only. All values in Table 73 are prefixed with
1.3.6.1.4.1.2979.11.5.2.
Table 73 WaveRider CCU Authorization Table MIB
CCU Authorization Table
All CCU Authorization Table Group MIB values are read only. All values in Table 74 are
prefixed with 1.3.6.1.4.1.2979.11.5.2.2.
Table 74 WaveRider CCU Authorization Table MIB
CCU RFC MIB-II Traps
RFC MIB-II Traps
Table 75 CCU RFC MIB-II Traps
MIB Name OID
Value
Type
Description
ccuAuthorizationCount 1 Integer Number of authorized EUMs.
ccuAuthorizationTable 2 MIB
MIB Name OID Type
Accepted
Values
Description
ccuAuthorizationIndex 1 Integer Index of entry in Authorization Table.
ccuAuthorizationId 2 Integer 000000-
FFFFFF
Integer representation of the EUM ID, normally
displayed in hexadecimal.
ccuAuthorizationGosClass 3 Integer 1: Best Effort
2: Bronze
3: Silver
4: Gold
5: Denied
The grade of service associated with the EUM.
MIB Name OID Description
coldStart 1.3.6.1.2.1.11.0.0 PowerCycleorPowerOn.
authenticationFailure 1.3.6.1.2.1.11.0.4 An SNMP request has failed due to improper
authentication.
