APCD-LM043-4.0 211
CCU Modem Information MIB
All values in Table 70 are prefixed with 1.3.6.1.4.1.2979.11.5.
Table 70 WaveRider CCU Modem Information MIB
CCU Registration Information MIB
All CCU Registration MIB values are read only. All values in Table 71 are prefixed with
1.3.6.1.4.1.2979.11.5.1
Table 71 WaveRider CCU Registration Information MIB
CCU Registration Table
All CCU Registration Table Group MIB values are read only. All values in Table 72 are prefixed
with 1.3.6.1.4.1.2979.11.5.1.2.
Table 72 WaveRider CCU Registration Table MIB
ccuEtherTxOk 18 Counter Number of packets sent correctly.
ccuEtherTxTimeout 19 Counter Number of times the packet transmit has timed out.
ccuEtherTxSemWait 20 Counter Number of times a transmit semaphore could not be
taken in the timeout period.
MIB Name OID
Value
Type
Description
MIB Name OID
Value
Type
Description
ccuRegistration 1 MIB Registration Table.
ccuAuthorization 2 MIB Authorization Table.
MIB Name OID
Value
Type
Description
ccuRegistrationCount 1 Integer Number of connections in the Registration Table.
ccuRegistrationTable 2 MIB
MIB Name OID
Value
Type
Accepted
Values
Description
ccuRegistrationIndex 1 Integer Index of entry in Registration Table.
ccuRegistrationId 2 Integer 000000-FFFFFF Integer representation of the EUM ID,
normally displayed in hexadecimal.
