208 APCD-LM043-4.0
ccuRadioMACRxPktsRuntFail 22 Counter Number of packets received that were shorter than
the minimum size.
ccuRadioMACRxPktsLongFail 23 Counter Number of packets received that were longer than the
maximum size.
ccuRadioMACRxPktsHCRCFail 24 Counter Number of packets received with a MAC header CRC
failure (header corrupted).
ccuRadioMACRxPktsICVFail 25 Counter Number of packets received with an encryption (WEP,
wireless equivalent privacy) key mismatch (see note
3).
ccuRadioMACRxPktsFCSFail 26 Counter Number of packets received with a Frame Check
Sequence failure (payload corrupted).
ccuRadioMACRxPktsAssocFail 27 Counter Number of times a received packet had to be
discarded because too many EUMs were already
associated.
ccuRadioMACRxPktsIncomplete 28 Counter Number of times the receive DMA for a payload does
not complete (internal error).
ccuRadioMACRxPayloadsFailFull 29 Counter Number of times a received payload has to be
discarded because either no receive descriptor was
available, or there was not enough buffer space.
ccuRadioMACRxPayloadsDelivered 30 Counter Number of payloads that this station received
correctly.
ccuRadioMACRxPktsEmpty 31 Counter Number of packets received with no payload.
ccuRadioMACTxPkts 32 Counter Number of packets transmitted.
ccuRadioMACTxPktsEmpty 33 Counter Number of packets transmitted with no payload.
ccuRadioMACTxPayloads 34 Counter Number of payloads transmitted.
ccuRadioMACTxPayloadsBroadcast 35 Counter Number of broadcast payloads transmitted.
ccuRadioMACTxPayloads1Ok 36 Counter Number of payloads acknowledged after the first
transmission.
ccuRadioMACTxPayloads2Ok 37 Counter Number of payloads acknowledged after the second
transmission.
ccuRadioMACTxPayloads3Ok 38 Counter Number of payloads acknowledged after the third
transmission.
ccuRadioMACTxPayloads4Ok 39 Counter Number of payloads acknowledged after the fourth
transmission.
ccuRadioMACTxPayloadsFailRetry 40 Counter Number of payloads that failed to transmit due to the
retry limit.
ccuRadioMACTxPayloadsFailDeleted 41 Counter Number of payloads discarded from a queue that was
emptied when an EUM was deregistered due to non-
response or deauthorization.
ccuRadioMACTxPayloadsBadParam 42 Counter Number of payloads returned to the host because
they are improperly formed (internal error).
ccuRadioMACTxPayloadsVnetInactive 43 Counter Number of payloads returned to the host because the
virtual net was not active (internal error).
MIB Name OID
Value
Type
Description
