APCD-LM043-4.0 207
ccuRadioMACRxPayloadFailInvalidType 3 Counter Number of times an unknown type of payload was
received from the air interface.
ccuRadioMACRxPayloadFailGiant 4 Counter Number of times a payload that was too long was
received from the air interface, and therefore
discarded.
CCURadioMACNullRxDesc 5 Counter Number of times the internal MAC receive interface
was corrupted.
ccuRadioMACTxDataPayloads 6 Counter Number of Ethernet frames transmitted to the air
interface.
ccuRadioMACTxCtrlPayloads 7 Counter Number of control payloads transmitted to the air
interface.
ccuRadioMACTxPayloadFailInvalidType 8 Counter Number of times a payload of an unknown type was
discarded.
ccuRadioMACTxPayloadFailGiant 9 Counter Number of times a payload that was too long was
discarded.
ccRadioMACTxPayloadFailInvalidDesc 10 Counter Number of times the internal MAC transmit interface
was corrupted.
ccuRadioMACTxBufferFullOnArrival 11 Counter Number of transmit packets that were queued for
delivery.
ccuRadioMACCmdTimeOuts 12 Counter Number of times the MAC-layer management
message was incomplete.
ccuRadioMACCmdMissedIRQs 13 Counter Number of times there was no response to the MAC-
layer management message.
ccuRadioMACFalseCmdIRQs 14 Counter Number of times a hardware IRQ was detected with
no message associated. This MIB parameter is used
primarily by software development.
ccuRadioMACCmdStatusErrors 15 Counter Number of times the MAC-layer management
message was rejected.
ccuRadioMACFatalError 16 Counter Number of nonrecoverable MAC-layer errors, each
causing a CCU reboot.
17 Reserved.
ccuRadioMACRxPacketsRedirected 18 Counter Number of times a reply from the EUM is received
with the correct HCRC (header cyclic redundancy
check).
Note: The name of this MIB is an error and should be
ccuRadioMACRxPacketsDirected.
ccuRadioMACRxPktsBroadcast 19 Counter Number of times an EUM succeeds in a random
access.
ccuRadioMACRxPktsNoMatch 20 Counter Number of packets correctly received, but not directed
to, this station.
ccuRadioMACRxPktsDuplicate 21 Counter Number of duplicate payloads (see note 1) received
and discarded. Indicates that a MAC layer
acknowledgement was lost.
MIB Name OID
Value
Type
Description
