CCU Radio MAC Statistics Group
All CCU Radio MAC Statistics Group MIB values are read only. All values in Ta ble 68 are
prefixed with 1.3.6.1.4.1.2979.11.3.3.
Table 68 WaveRider CCU Radio MAC Statistics Group MIB
ccuRadioDrvUnknownEvent 7 Counter Number of received an unknown/no event interrupts
received by the radio driver ISR.
ccuRadioDrvSend 8 Counter Number of packets sent successfully by the radio driver
transmit queue.
ccuRadioDrvSendQFull 9 Counter Number of packets not sent because the radio driver
transmit queue was full.
ccuRadioDrvSendUnavailable 10 Counter Number of times invalid (null) mblks were sent to the radio
driver for transmission.
ccuRadioDrvSendNotEnabled 11 Counter Number of times tried to send packets before the radio
driver was started; i.e., before the device was up and
working.
ccuRadioDrvAMMPut 12 Counter Number of times a packet was successfully sent to the
MAC-layer shared memory for transmission over the air.
ccuRadioDrvAMMQFull 13 Counter Number of times a packet could not be sent to the MAC-
layer shared memory because there were no transmit
descriptors left. Radio driver tries 5 more times to send
the packet.
ccuRadioDrvAMMQFullDiscard 14 Counter Number of times, after 5 attempts, a packet could not be
sent to the MAC-layer shared memory because there
were no transmit descriptors left. Packet is discarded.
ccuRadioDrvGet 15 Counter Number of packets received from the MAC-layer shared
memory.
ccuRadioDrvQEmpty 16 Counter Number of times there was a receive interrupt, but nothing
available to read out of the MAC-layer shared memory.
ccuRadioDrvRx 17 Counter Number of successfully received packets.
ccuRadioDrvRxNotAvailable 18 Counter Number of times the radio driver could not allocate an
mblk (memory block) for storing a packet retrieved from
the MAC-layer shared memory.
ccuRadioDrvRxNotEnabled 19 Counter Number of times the radio driver received a receive
interrupt, but the radio driver was not yet up and running.
The received packet is ignored in this case.
MIB Name OID Value Type Description
MIB Name OID
Value
Type
Description
ccuRadioMACRxDataPayloads 1 Counter Number of Ethernet frames received correctly from
the air interface.
ccuRadioMACRxCtrlPayloads 2 Counter Number of control payloads received correctly from
the air interface.
