APCD-LM043-4.0 205

CCU Radio Statistics Group

All CCU Radio Statistics Group MIB values are read only. All values in Table 65 are prefixed

with 1.3.6.1.4.1.2979.11.3.

Table 65 WaveRider CCU Radio Statistics MIB

CCU Radio General Statistics Group

All CCU Radio General Statistics Group MIB values are read only. All values in Table 66 are

prefixed with 1.3.6.1.4.1.2979.11.3.1.

Table 66 WaveRider CCU Radio General Statistics Group MIB

CCU Radio Driver Statistics Group

All CCU Radio Driver Statistics Group MIB values are read only. All values in Ta ble 67 are

prefixed with 1.3.6.1.4.1.2979.11.3.2.

Table 67 WaveRider CCU Radio Driver Statistics Group MIB

MIB Name OID

Value

Type

Description

ccuRadioStatsGeneral 1 MIB General radio statistics.

ccuRadioStatsDriver 2 MIB Radio driver statistics

ccuRadioStatsMAC 3 MIB Radio MAC statistics.

MIB Name OID Value Type Description

ccuRadioGenRSSI 1 Integer Not used.

ccuRadioGenTPI 2 Integer Radio transmit power indicator.

MIB Name OID Value Type Description

ccuRadioDrvEvents 1 Counter Number of interrupts received (any interrupt) in the radio

driver ISR (Interrupt Service Routine)

ccuRadioDrvRxComplete 2 Counter Number of

receive complete interrupts received by the

radio driver ISR.

ccuRadioDrvTxComplete 3 Counter Number of

transmit complete interrupts received by the

radio driver ISR.

ccuRadioDrvCmdComplete 4 Counter Number of

command complete interrupts received by the

radio driver ISR.

ccuRadioDrvFatalEvent 5 Counter Number of

fatal error interrupts received by the radio

driver ISR.

ccuRadioDrvTxPowerRailEvent 6 Counter Number of

Tx Power alarm interrupts received by the

radio driver ISR.
