User's Manual

204 APCD-LM043-4.0
CCU General Information Group
All values in Table 63 are prefixed with 1.3.6.1.4.1.2979.11.1.
Table 63 WaveRider CCU General Information Enterprise MIBs
CCU Radio Configuration Group
All CCU Radio Configuration Group MIB values are read only. All values in Ta ble 64 are
prefixed with 1.3.6.1.4.1.2979.11.2.
Table 64 WaveRider CCU Radio Configuration Enterprise MIBs
MIB Name OID Value Type Status
Accepted
Values
Description
ccuSerialNumber 1 String R CCU hardware serial number
ccuSoftwareVersion 2 String R CCU firmware version.
ccuHardwareVersion 3 String R CCU hardware version.
ccuExtraFunctions 4 Integer R 0 A mask for extra functionality that may
be added at a later date. For now, it
returns ‘0’.
ccuGlobalStatus 5 Integer R 1: startup
2: dead
3: ok
4: suspect
Current status of the radio interface.
For now, this field returns ‘ok’.
ccuGlobalSaveCounter 6 Counter R A count of the number of times the
configuration is saved. Initially, this field
always returns ‘0’.
ccuGlobalConfigFiles 7 String R A list of configuration files for the CCU.
The list is delimited with a semicolon;
i.e., “basic.cfg;route.cfg, ...”
ccuGlobalReset 8 Integer W 1: reset Not functional at this time.
ccuGlobalReload 9 Integer W 1: reload Not functional at this time.
MIB Name OID
Value
Type
Accepted
Values
Description
ccuRadioConfigVersion 1 String Radio firmware version.
ccuRadioConfigMacAirlinkAddr 2 Phys
Address
MAC address Radio MAC address.
ccuRadioConfigFrequency 3 Integer Radio frequency in use (in 1/10ths of a
MHz)
ccuRadioConfigDomain 4 Integer 0: IEEE
1: FCC or IC/
Canada
Current regulatory domain for which the
radio is configured.
ccuRadioHardwareRevision 5 String Radio hardware revision.
