APCD-LM043-4.0 203
WaveRider CCU Enterprise MIBs
The structure of the CCU MIBs is illustrated in Figure 51.
Figure 51 CCU MIBs
Each of the MIBs in Figure 51 is discussed in the following sections.
CCU Base MIB
All values in Table 62, which are read only, are prefixed with 1. 3. 6.1.4.1. 2979.11.
Table 62 WaveRider CCU Base MIB
MIB Name OID Value Type Description
ccuGlobal 1 MIB CCU general data.
ccuRadioConfig 2 MIB CCU configuration and setup data.
ccuRadioStats 3 MIB CCU radio statistics.
ccuEtherStats 4 MIB CCU Ethernet statistics
ccuModems 5 MIB CCU registration and authorization information.
WaveRider (2979)
waverider
ccuGlobal
ccu3000pmacglob
ccuRadioConfig
ccu3000pmacradcfg
ccuRadioStats
ccu3000pmacrs
ccuEtherStats
ccu3000pmaces
ccuModem
ccu3000pmacmodem
ccuRadioStatsGeneral
ccu3000pmacrsgen
ccuRadioStatsDriver
ccu3000pmacrsdrv
ccuRadioStatsAtmel
ccu3000pmacrsatmel
ccuRegistration
ccu3000pmacreg
ccuAuthorization
ccu3000pmacauth
Enterprise (1.3.6.1.4.1)
LMS3000 CCU
ccu3000pmac
MIB Name
MIB File Prefix
Legend
