Interfaces Group MIB
Table 60 provides the details of the Interfaces group MIB mentioned above. All values in the
followingtableareprefixedwith1.3.6.1.2.1.2.
Table 60 MIB-II Interface List Header MIB
All values in Table 61 are prefixed with 1.3.6.1.2.1.2.2.1, as defined in RFC1213, and are read
only.
Table 61 MIB-II Interface List Table MIB
at 3 MIB R This group shows the address translation table, mapping Ethernet
addresses to IP addresses. This group is only for MIB-I
compatibility.
ip 4 MIB R This group provides all of the statistics on IP traffic that is routed
through the modem. For EUMs, all traffic from the end-user to the
CCU bypass the IP stack in the EUM so these numbers are only
for the EUM applications. For the CCU, all IP traffic through the
CCU router application, including CCU application traffic.
icmp 5 MIB R This groups provides statistics on all ICMP packets processed by
the IP stack.
tcp 6 MIB R This provides counters for all TCP packets processed by the
modem. Only TCP packets sent or received by the modem
applications are counted (e.g. FTP or Telnet sessions directly to
the modem) since any packets for other hosts are routed by the IP
protocol and never reach the TCP protocol.
udp 7 MIB R Counters for all UDP packets processed by the modem's
applications. Only UDP packets sent or received by the modem
applications are counted (e.g. FTP or Telnet sessions directly to
the modem) since any packets for other hosts are routed by the IP
protocol and never reach the UDP protocol.
snmp 11 MIB R Counters for all SNMP packets process by the modem's
applications.
MIB Name OID Type Status Description
ifIndex 1 Integer R The number of entries in ifTable.
ifTable 2 MIB Thelistofinterfaces.
MIB Name OID Type Status Description
MIB Name OID
Value
Type
Accepted Values Description
ifIndex 1 Integer A unique value for each interface. Its value
ranges between 1 and the value of ifNumber.
The value for each interface must remain
constant at least from one re-initialization of
the entity's network management system to
the next re-initialization.
