198 APCD-LM043-4.0
-j host-list Sends the ICMP Echoes using the Loose Source Route option
and sets the next hop addresses to the IP addresses in the host
list. The host list is made up of IP addresses separated by spaces
corresponding to the loose source route. There can be up to nine
IP addresses in the lost list.
Not set
-k host-list Sends the ICMP Echoes using the Strict Source Route option and
sets the next hop addresses to the IP addresses in the host list.
The host list is made of IP addresses in the host list. The host list
is made of IP addresses separated by spaces corresponding to
the loose source route. There can be up to 9 IP addresses in the
host list.
Not set
-w timeout Waits the specified amount of time, in milliseconds, for the
corresponding Echo Reply before displaying a Request Timed
Out message.
1000
Option Use Default
