Table 57 RSSI/RSS Cross-reference for Sample Unit (at 915MHz)

As shown in Table 57, using these simple rules means that the RSS values midway between

the calibration points may not exactly line up, but the results will be within the accuracy of the

measurement. The Configuration Utility automatically calculates and displays the current

received signal strength, and a histogram of the received signal strength.

System Status File (CCU and EUM)

The System Status File is a record of the results of the CCU and EUM POST (Power On Self

Test ).

To view the System Status File:

Console> sys ss

POST Results:

-----------------------

Registers......Passed

Timers.........Passed

SDRAM..........Passed

Watchdog.......Passed

TFFS...........Passed

PCMCIA.........Not run

Ethernet.......Passed

MAC............Passed

Radio..........Not run

USB............Not run

RS232_1........Not run

RS232_2........Not run

File Status:

-----------------------

perm.cfg........Opened-OK

basic.cfg.......Opened-OK

route.cfg.......Test Not Run

sa1110.exe......Opened-OK

netdb.cfg.......Test Not Run

RSSI RSS RSSI RSS RSSI RSS RSSI RSS RSSI RSS

39 -83dBm 48 -74dBm 57 -64dBm 66 -58dBm 75 -49dBm

40 -82dBm 49 -72dBm 58 -63dBm 67 -57dBm 76 -48dBm

41 -81dBm 50 -71dBm 59 -62dBm 68 -56dBm 77 -47dBm

42 -80dBm 51 -70dBm 60 -61dBm 69 -55dBm 78 -46dBm

43 -79dBm 52 -69dBm 61 -60dBm 70 -54dBm 79 -45dBm

44 -78dBm 53 -68dBm 62 -59dBm 71 -53dBm 80 -44dBm

45 -77dBm 54 -67dBm 63 -58dBm 72 -52dBm 81 -43dBm

46 -76dBm 55 -66dBm 64 -57dBm 73 -51dBm 82 -42dBm

47 -75dBm 56 -65dBm 65 -59dBm 74 -50dBm 83 -41dBm
