NOTE: The air command has been used to view the Registration
Table, because reg is too close to reb (reboot).
ARP Map Table (CCU and EUM)
For each host (EUM or PC) in the system, the ARP Map Table displays the following entries:
Table 55 ARP MAP Table Entries
The ARP MAP Table is built automatically by the CCU, from information contained in the
Address, ARP and Registration Tables. Its primary use is to summarize the information in
these tables in a user-friendly format, for presentation to the system operator.
To vie w t he ARP MAP Ta ble :
Console> arp map
ARP MAP TABLE
IP Address Ethernet EUMID GOS Last Rx
10.5.0.10 00:90:c8:60:02:79 60:02:79 silver 24
10.5.0.11 00:90:c8:60:04:a3 60:04:a3 silver 19
10.5.0.12 00:90:c8:60:03:f6 60:03:f6 gold 23
10.5.0.13 00:90:c8:60:00:a9 60:00:a9 bronze 0
10.5.0.14 00:90:c8:60:0a:33 60:0a:33 silver 24
10.5.0.16 00:90:c8:60:00:ef 60:00:ef gold 21
10.5.0.17 00:90:c8:60:00:4a 60:00:4a gold 20
10.5.0.18 00:90:c8:60:00:46 60:00:46 gold 23
10.5.0.31 00:90:c8:60:03:75 60:03:75 gold 14
10.5.1.14 00:01:03:04:f7:d8 60:0a:33 silver 24
10.5.1.16 00:01:02:2b:b2:99 60:00:ef gold 21
10.5.1.17 00:50:da:bb:d1:de 60:00:4a gold 20
10.5.2.50 00:50:ba:b3:97:cd 60:02:79 silver 24
10.5.2.54 00:50:da:b7:25:2f 60:00:a9 bronze 0
Console>
Table Entry Description
IP Address Host IP address
Ethernet Host Ethernet MAC address
EUMID EUM ID
GOS EUM Grade of Service
Last Rx
Number of seconds since the last payload was received from the
EUM.
