Registration Table (CCU only)
The Registration Table contains a list of all registered EUMs. The CCU automatically builds
and adds to this table as EUMs communicate with the CCU. Every EUM that registers with the
CCU appears in this table. The EUM will be removed from the Registration Table if the:
• EUM has not communicated with the CCU for more than 12 hours because:
• the EUM has been turned off for more than 12 hr., or
• theEUMhashadnotraffictosendformorethan12hr.,or
• the EUM has lost its RF connection to the CCU for more than 12 hr.
• EUM does not respond to traffic from the CCU. In this case, the EUM will be removed
immediately from the Registration Table.
The Registration Table contains the following entries:
Table 54 Registration Table Entries
To view the Registration Table:
Console> air
Maximum Associations : 75
Deregistration Count : 8
REGISTERED EUMs
EUM ID GOS Level Time[s]
--------------------------------
60:03:75 gold 22
60:0a:33 silver 2
60:00:ef gold 29
60:00:46 gold 1
60:00:4a gold 0
60:00:f5 gold 1522
60:02:79 silver 1
60:03:f6 gold 1
60:04:a3 silver 27
60:00:a9 bronze 0
--------------------------------
Table Entry Description
EUM ID EUM ID
GOS Level Grade of Service Class
Time (s) Time since the last payload was received from the EUM.
Maximum Associations
The maximum number of EUMs that can be associated at
any one instant in time.
Deregistration Count
An EUM will be de-registered if it does not respond after
the CCU has sent it this many consecutive polls.
