APCD-LM043-4.0 177
radio rc Clears the CCU RSSI and transmit power
level history.
radio rf high|low Displays or sets the power of the EUM
radio. Note: The EUM RF level should
always be set to high.
radio rh Displays the RSSI and transmit power level
history.
radio rssi Displays continuous RSSI readings. Press
any key to halt.
reg eum Forces the EUM to request registration.
reset|reboot Reboots the EUM.
save|commit Saves configuration changes.
snmp Displays the EUM SNMP information.
snmp community Displays the SNMP communities.
snmp community add <community>
<read|write>
Adds an SNMP community, where.
• <community> isthenameofthe
SNMP community being added, from 1-
32 characters in length.
• Enter <read> or <write> to indicate
the type of the community being added.
snmp community delete
<community>
Deletes an SNMP community, where.
• <community> isthenameofthe
SNMP community being deleted.
snmp contact Displays the SNMP system contact.
snmp contact <contact> Changes the SNMP system contact, where:
• <contact> is name of the EUM SNMP
system contact (subscriber, for
example), from 1-80 characters in
length.
snmp interface Displays the interface MIBs.
snmp location Displays the SNMP system location.
snmp location <location> Changes the SNMP system location, where:
• <location> is the location of the
EUM, from 1-80 characters in length.
snmp trap Displays the SNMP Trap Server Table.
Command Syntax (EUM) Command Description
