APCD-LM043-4.0 173
time relay ip|destination
<aaa.bbb.ccc.ddd>|broadcast
Sends NTP messages to a single EUM,
where:
• <aaa.bbb.ccc.ddd> is the IP
address of the EUM.
or sends NTP messages to all EUMs if
broadcast is entered.
time server ? Displays NTP server utilities.
time server port <port> Changes the SNTP server port, where:
• <port> is the port number.
time server stratum <value> Sets NTP stratum or relative stratum offset,
where:
• <value> is the NTP offset, from 1-5
when sync, and 6-15 when unsync.
time set <time>. Sets the system time (Greenwich Mean
Time), where:
• <time> is formatted [dy-mon-year
hh:mm:ss] or [mm-dd-yy hh:mm:ss}.
This command overwrites the local time
obtained from the NTP server. The local
time will be updated on the next refresh from
the NTP server.
time stats Displays time statistics.
Command Syntax (CCU) Command Description
