172 APCD-LM043-4.0
sys wlog <text> Writes text to the log file. This command is
useful for adding information to the log for
subsequent analysis:
• <text> may be from 1-80 characters
in length.
time Displays the system calendar clock time.
time add <aaa.bbb.ccc.ddd> Adds an NTP server, where:
• <aaa.bbb.ccc.ddd> is the NTP
server address.
time client Manages the SNTP client and displays a list
of NTP servers.
time client disable Disables the SNTP client.
time client enable Enables the SNTP client.
time client port <port> Changes the SNTP client port number:
• <port> is the port number. The default
port number is 123.
time client resync <seconds> Sets the client resync period, where:
• <seconds> is the resync period in
seconds,
time client retry <seconds> Sets the client retry period, where:
• <seconds> is the retry period in
seconds.
time delete <aaa.bbb.ccc.ddd> Deletes an NTP server, where:
• <aaa.bbb.ccc.ddd> is the NTP
server address.
time flush Deletes all NTP servers.
time flush default Deletes all NTP servers and restores
defaults.
time get Displays the system time.
time print Prints the SNTP configuration and NTP
server list.
time refresh|update Forces an NTP time update.
time relay ? Lists SNTP relay commands.
time relay enable Enables SNTP relay over the radio
interface.
time relay disable Disables SNTP relay over the radio
interface.
Command Syntax (CCU) Command Description
