APCD-LM043-4.0 169
radio frequency Displays the CCU radio frequency in tenths
of a MHz; for example, 905.0 MHz is
displayed as 9050.
radio frequency <frequency> Changes the CCU radio frequency, where.
• <frequency> is the new radio
frequency, in tenths of a MHz; for
example, 905.0 MHz is entered as
9050.
radio meter Displays the current Polling MAC load. This
information is displayed for each GOS.
radio rc Clears the CCU RSSI and transmit power
level history.
radio rf high|low Displays or sets the power of the CCU radio.
Note: The CCU RF level should always be
set to high.
radio rh Displays the RSSI and transmit power level
history.
radio rssi Displays continuous RSSI readings. Press
any key to halt.
rcf Displays the contents of the route
configuration file (RCF).
reset|reboot Reboots the CCU.
route Displays the routing table for the CCU.
route add <aaa.bbb.ccc.ddd>
<eee.fff.ggg.hhh> (0-32)
Adds a route to the routing table. This
command applies only to the CCU.
• <aaa.bbb.ccc.ddd> is the Ethernet
IP address of the network being added
to the routing table.
• <eee.fff.ggg.hhh> is the Ethernet
IP address of the gateway through
which the destination is reached.
• (0-32) is the netmask for the
destination network.
Command Syntax (CCU) Command Description
