160 APCD-LM043-4.0
Radio IP Address 192.168.11.1
Radio Netmask 24
Registration Server IP Address 0.0.0.0
Registration Server Netmask 0
SNMP Contact WaveRider Communications Inc.
SNMP Location www.waverider.com
SNMP Read Communities public
SNMP Write Communities private
SNMP Traps None entered
SNTP Client Enabled No
SNTP Client Resynchronization Period 3600 seconds
SNTP Client Retry Period 30 seconds
SNTP Relay Enabled Yes
SNTP Relay Send Time on Boot Yes
SNTP Relay Send Time on EUM
Registration
Yes
SNTP Servers 132.246.168.148 (time.nrc.ca)
140.162.8.3 (ntp.cmr.gov)
136.159.2.1 (ntp.cpsc.ucalgary.ca)
192.5.5.250 (clock.isc.org)
127.0.0.1 (local host)
Transmit Power HIGH
Table 43 EUM Factory Configuration
Parameter Default Configuration
Console Prompt The default console prompt is the station
(EUM) ID.
Ethernet IP Address 192.168.10.250
Ethernet Netmask 24
Gateway IP Address 192.168.10.1
Maximum Bridge Table Size 256
Maximum Number of Customers 1
Password <cr>
Table 42 CCU Factory Configuration
Parameter Default Configuration
