User's Manual
Table Of Contents
- Contents
- Contents v
- Figures ix
- Tables xi
- Preface xv
- Appendix A Specifications 157
- Appendix B Factory Configuration 159
- Appendix C CommandLine Syntax 163
- Appendix D Antenna Guidelines 181
- Appendix E CCU/EUM Data Tables 183
- Appendix F Ping Commands 197
- Appendix G SNMP MIB Definitions 199
- Appendix H Operating Statistics 223
- Appendix I IP Plan — Example 241
- Appendix J Acronyms and Glossary 253
- Index 261
- Figures
- Tables
- Preface
- 1 Introduction
- 2 Quick Startup
- 3 Detailed Description
- 4 IP Network Planning
- 5 Radio Network Planning
- 6 Installation/Diagnostic Tools
- 7 Configuring the CCU
- 7.1 CCU and EUM Serial Number, MAC Address, and Station ID
- 7.2 Setting the CCU Password
- 7.3 Configuring the CCU RF Parameters
- 7.4 Configuring CCU IP Parameters
- 7.5 Configuring DHCP Relay
- 7.6 Configuring Port Filtering
- 7.7 Configuring the SNTP/UTC Time Clock
- 7.8 Configuring SNMP
- 7.9 Adding EUMs to the Authorization Table
- 8 Configuring the EUM
- 9 Installing the EUM
- 9.1 Before you Start the EUM Installation
- 9.2 Other EUM Programming Considerations
- 9.3 Installation Overview
- 9.4 Installation Procedures
- 9.4.1 Opening the Box
- 9.4.2 Turning off the End-user’s Cordless Phones
- 9.4.3 Choosing a Location for the EUM and Antenna
- 9.4.4 Connecting the EUM Components
- 9.4.5 Conducting a Preliminary Check of the EUM
- 9.4.6 Positioning the Antenna
- 9.4.7 Mounting the Antenna
- 9.4.8 Connecting the End-user’s PC
- 9.4.9 Obtaining Valid IP Addresses for the End-user’s PC
- 9.4.10 Testing the Data Link
- 9.4.11 Configuring the Browser Application
- 9.4.12 Completing the Installation
- 9.4.13 Baselining the Installation
- 9.4.14 Troubleshooting
- 10 Maintaining the Network
- 11 Monitoring the Network
- 12 Troubleshooting
- 13 Specialized Applications
- Appendix A Specifications
- Appendix B Factory Configuration
- Appendix C CommandLine Syntax
- Appendix D Antenna Guidelines
- Appendix E CCU/EUM Data Tables
- Appendix F Ping Commands
- Appendix G SNMP MIB Definitions
- MIB-II Elements Supported from RFC-1213
- WaveRider CCU Enterprise MIBs
- CCU Base MIB
- CCU General Information Group
- CCU Radio Configuration Group
- CCU Radio Statistics Group
- CCU Radio General Statistics Group
- CCU Radio Driver Statistics Group
- CCU Radio MAC Statistics Group
- CCU Ethernet Statistics Group
- CCU Modem Information MIB
- CCU Registration Information MIB
- CCU Registration Table
- CCU Authorization Information MIB
- CCU Authorization Table
- CCU RFC MIB-II Traps
- WaveRider EUM Enterprise MIBs
- EUM RFC MIB-II Traps
- Appendix H Operating Statistics
- Appendix I IP Plan — Example
- Appendix J Acronyms and Glossary
- Index
APCD-LM043-4.0 159
Appendix B Factory Configuration
This appendix identifies the factory configuration settings for the CCU and EUM.
Table 42 CCU Factory Configuration
Parameter Default Configuration
Console Prompt The default console prompt is the station
(CCU) ID.
Deregistration Count 8
DHCP Relay Disabled
Ethernet IP Address 192.168.10.250
Ethernet Netmask 24
Gateway IP Address 192.168.10.1
GOS Definitions BE (0 - 384 kbps)
Bronze (0 - 1024 kbps)
Silver (128 - 256 kbps)
Gold (256 - 512 kbps)
Denied (0 kbps)
Note: The above data rates are based on
FTP transfers from a single EUM, using
maximum-sized packets)
GOS Default (Authorization Table) BE (Best Effort)
Maximum Associations 75
Password <cr>
Port Filters 137 (both)
138 (both)
139 (both)
1512 (both)
Radio Frequency 9050 (905.0MHz)
