158 APCD-LM043-4.0
Table 39 Ethernet Interface Specifications
Table 40 Power Supply Specifications
Table 41 Environmental Specifications
Co-located Channel Set Center
Frequencies (standard)
905 MHz, 915 MHz, 925 MHz
Note: Other frequencies can be used,
depending on site-specific considerations.
Call WaveRider for more information.
Modulation Scheme Based on DSSS (Direct-Sequence Spread
Spectrum) signals, modulated with CCK
(Complementary Code Keying), and Barker-
coded BPSK (Binary Phase Shift Keying)
and QPSK (Quaternary Phase Shift Keying)
Receiver Sensitivity for BER < 10
-5
Better than -86 dBm
Maximum Over-the-Air, Raw Data Rate 2.75 Mbps
Maximum Output Power +26 dBm
CCU Physical Interface 10BaseT (Ethernet)
EUM Physical Interface 10BaseT (Ethernet)
AC Input 110/230 ± 15% VAC, single phase
AC Input Frequency 50/60 ± 3 Hz
Maximum Input Current 0.2 A
Operating Temperature 0°C to +50°C, indoor CCU
10°C to +40°C, indoor EUM
(10%-80% RH non-condensing)
Storage Temperature -40°C to +70°C
