APCD-LM043-4.0 157

Appendix A Specifications

This appendix lists the following specifications for the LMS4000 900 MHz Radio Network,

specifically the technical specifications for the CCU and EUM, configured for operation in the

FCC/IC RF regulatory domain:

• Radio Specifications on page 157

• Ethernet Interface Specifications on page 158

• Power Supply Specifications on page 158

• Environmental Specifications on page 158

Table 38 Radio Specifications

Maximum Number of Operational CCUs and

Orthogonal Channels

Maximum Number of EUMs per CCU 300

The maximum number of subscribers is

limited by the terms of the user license

purchased from WaveRider.

Minimum Channel Center Frequency 905 MHz

Maximum Channel Center Frequency 925 MHz

Channel Bandwidth 5.5 MHz

Center Frequency Spacing Increment 0.2 MHz (101 channels possible)

Minimum Separation Between Co-located

Channels

6.6 MHz

Maximum Co-located Channels 3
