APCD-LM043-4.0 155
13 Specialized Applications
The advanced capabilities of the LMS4000 900 MHz radio network modems can support a
variety of special applications.
13.1 EUM Thin Route
In some cases, it may be cost-effective to use an EUM to extend the reach of the LMS4000
900 MHz radio network to small numbers of outlying EUMs, as shown in Figure 49.
Figure 49 Using an EUM for Thin Route
CCU3000
Antenna
CCU3000
Antenna
Standard
EUM3000
Thin Route
EUM3000
Hub
Standard
EUM3000
Standard
EUM3000
End-user PC
End-user PC
End-user PC
End-user PC
Radio
Channel "A"
Radio
Channel "B"
