9 Installing the EUM
APCD-LM043-4.0 107
11. Configuring the Browser Application on page 119
12. Completing the Installation on page 120
13. Baselining the Installation on page 120
9.4 Installation Procedures
9.4.1 Opening the Box
Before you install the EUM components, verify that the EUM kit is complete.
EUM Kit Components
• EUM modem
• AC/DC power supply with 2-meter DC power cable
• 2-meter AC power cable
• Crossover Ethernet cable
Antenna Kit Components
• Indoor antenna with attached 3-meter cable
• Flush-mountable antenna bracket
• Two antenna-mount suction cups, two drywall plugs, and two screws
Refer to Figure 37 for an illustration of each EUM component.
Figure 37 EUM Components
NOTE: The antenna-mount suction cups, drywall plugs, and screws are
not shown in Figure 37.
EUM
Ethernet
Cable
Antenna
Bracket
Antenna with attached cable
AC Power Cable
AC/DC adapter with
C power cable attached
