9 Installing the EUM
106 APCD-LM043-4.0
9.2 Other EUM Programming Considerations
Although the IP settings identified above are required for basic EUM operation, you should
also consider pre-configuring the following EUM parameters:
SNMP
SNMP communities can be configured in the EUM to enable remote monitoring of the EUM
using an SNMP manager. Refer to Configuring SNMP on page 102.
Customer List
The factory default configuration allows only one PC to be logically connected to the EUM at
any given time. If you want to use a separate PC as an aid to installing and confirming the
EUM link prior to connecting the end-user PC, then you will have to reset the EUM when
changing between the end-user PC and the installation test PC.
Port Filtering
Port filtering is set in the EUM to filter out Network Neighborhood. You can edit Port filtering in
theEUM,ifdesired.RefertoConfiguring Port Filtering on page 101.
Output Power
In most cases, the EUM output power should be set to HIGH.
9.3 Installation Overview
Installing the EUM involves the following procedures:
1. Opening the Box on page 107
2. Turning off the End-user’s Cordless Phones on page 108
3. Choosing a Location for the EUM and Antenna on page 108
4. Connecting the EUM Components on page 108
5. Conducting a Preliminary Check of the EUM on page 110
6. Positioning the Antenna on page 111
7. Mounting the Antenna on page 112
8. Connecting the End-user’s PC on page 115
9. Obtaining Valid IP Addresses for the End-user’s PC on page 116
10. Testing the Data Link on page 116
