8 Configuring the EUM
104 APCD-LM043-4.0
8.6 Configuring the Customer List
You can set the maximum number of customers or PCs (customer_max) that can concurrently
access the radio link through the EUM, as described in Customer Table (EUM only) on page
192.
CAUTION: The simulation data presented in Performance
Modelling on page 42 is based on one end user (one PC) per
EUM. If customer_max is set to a value greater than ‘1’, and there
is more than one end user per EUM, the throughput performance
of the radio link will be affected.
TIP: When you are locally troubleshooting the EUM installation, if
customer_max is set to ‘1’ and you want to substitute and use a
known-working PC in place of the end-user’s PC, you will have to
reset the EUM or wait for the Customer Table to time out.
To set customer_max
1. Type cust max <value> and press Enter.
• <value> is the maximum number of customers (PCs), from 1-50.
2. Type save or commit and press Enter.
Example:
The following example
•Setscustomer_max to 3,
• Saves the new setting, and
• Displays the value of customer_max.
Console>
Console> cust max 3
Maximum customers: 3
Console>
Console> save
Basic Config saved
Port Filter Config saved
sntp cfg file saved
Console>
Console> cust max
Maximum customers: 3
Console>
Console>
