7 Configuring the CCU
86 APCD-LM043-4.0
• Saves the new settings,
• Reboots the CCU so that the new parameters take effect, and
• Displays the CCU RF parameters.
Console>
Console> radio frequency 9170
Console> radio rf high
Console>
Console> save
Basic Config saved
Port Filter Config saved
sntp cfg file saved
Route Config saved
Authorization Database saved
DHCP Server Config saved
Console>
Console> reset
rebooting CCU ...
(... Power On Self Test ...)
WaveRider Communications, Inc. LMS3000
Password:
Console>
Console> radio
RF Power: HIGH
Radio Frequency: 9170
Console>
7.4 Configuring CCU IP Parameters
In IP Network Planning on page 53, you determined the following:
• CCU gateway IP address and subnet mask
• CCU radio IP address and subnet mask
• CCU Ethernet IP address and subnet mask
To set the CCU Ethernet IP address
1. Type ip ethernet <aaa.bbb.ccc.ddd> <net mask> and press Enter.
• <aaa.bbb.ccc.ddd> is the CCU Ethernet IP address.
• <net mask> is the net mask.
CAUTION: The CCU only accepts subnet masks using the
shorthand notation; for example, it accepts ‘16’, but not
‘ffff0000’or‘255.255.0.0’.
2. Type save or commit and press Enter.
3. Before the new CCU Ethernet IP address will take effect, you must reboot the CCU by
typing reset and pressing Enter.
