User guide

Using the Scheduler
ETV Portal Server User Guide 37
3. Select the destination VBrick(s) or IPR(s) that will receive the video and click Finish.
4. Verify the information and click
Create Schedule to add the new schedule to the
calendar.
T To use Enter Manually as the Video Source
1. Select Enter Manually and click Next.
2. Enter the
Schedule Start Options and click Next. The options vary as follows depending
on the Source device type.
Source Select one: MPEG-1, MPEG-2, MPEG-4, or WM.
Source IP Address Destination multicast IP address that will receive the broadcast. Range
224.0.0.0–239.255.255.255.
Port Destination port number that will receive the broadcast. Range
1040–65534.
