User guide

34 © 2009 VBrick Systems, Inc.
When done, the named schedule is added to the calendar page of scheduled events. Any
scheduled links use color-coded text as shown in Table 6.
Table 6. Color-coded Scheduled Events
Advanced Settings
Advanced Settings are available to configure VBricks and IPRs with exceptional
configuration parameters—often with help from VBrick Support Services. It is unlikely you
will ever need to change these settings. In all cases you can safely ignore these settings and use the
defaults provided by the Portal Server. The available settings depend on the device
characteristics. For example, the following window shows advanced settings for an MPEG-4
encoder. See the VB4000-5000-6000 Admin Guide for more about these device settings.
Text Color Description
Red Expired. The scheduled event is over.
Yellow Future. The scheduled event will occur in the future.
Green Active. The scheduled event is currently in progress. If the event is
viewable (for example a stored video), a TV icon is displayed and you
can click on it to launch the stream.
