Installation Sheet

161120

Protected Flim

Function and Operation

TURNING LIGHTS ON, OFF

Wave hand under 4 inches of

sensor once to turn light on or off.

LOCK / UNLOCK LIGHT

Wave hand under 4 inches of sensor

within 0. 5 seconds twice to lock or

unlock sensor.

NOTE: Dimming ranges from 100%

to 5% brightness.

DIMMING LIGHTS

Hold hand under 4 inches of sensor

to adjust brightness.

ON-OFF

LOCK-UNLOCK

DIMMING

Note: This portable lamp has a polarized plug (one blade is wider than the other). As a safety feature, this plug will fit in a

polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a

qualified electrician. Never use with an extension cord unless plug can be fully inserted. Do not attempt to work around

this safety feature.

Arm

Plastic Clip

Inner Arm

Lock Screw

Fig.2

Fig.3

4. Pull the inner arm out from arm

completetly and another person pull the

the fixture wires. Then remove the

protected film from the inner arm. (Fig.2)

Note: Hold the plastic clip to

prevent inner arm from scuffing .

5. Insert the inner arm into the arm and

slide the plastic clip back into the arm

to prevent the inner arm from scuffing.

Place the inner arm to the desired

location and tighten lock screw back to

arm. (Fig.3)

Note: Hold the inner arm up for

suceeding in screwing lock

screw and to prevent it from

scuffing.

Note: Restore the plastic clip as

sooner to prevent inner arm

from scuffing.
