Installation Sheet

PAGE: 4 / 5
090406
F A N C OF A N C O
Turn ON the electric power at the
main fuse or circuit breaker box.
The slide switch sets the direction of fan rotation. Select the direction
of fan rotation you need by sliding the switch.
Push the slide switch left for " Forward" and right for "Reverse".
Fig.20
Slide Switch
Forward
Reverse
Fig.19
Fig.21
MED
HI
LOW
Install the battery to the transmitter (9V, not included).
* Press "HI" to turn on the fan at high speed.
* Press "MED" button to turn the fan in medium speed.
* Press "LOW" button to turn the fan in low speed.
* Press "FAN/OFF" button to turn off the fan.
* Press and release the " " button quickly to turn on/off the fan light.
FAN/OFF
MED
HI
FAN/OFF
LOW
* By using the dimmer function, press and hold the “ ” button to adjust the
illumination of light.
