Installation Sheet

161120
A: 18"
B: 84"
C:46”~56.5”
B
C
A
Mounting Hardware
5763MM(1 SET)
Metal Pad (B)
Lock Nut (A)
Set Screw X1
5761SS for L0001/L0002
5762SS for L0003/L0004
5-YEAR LIMITED WARRANTY:
All products are warranted to be free of defects in material and workmanship for five (5) years from date of
purchase. This warranty is limited to the correction of any such defect, or the replacement of any such defective
item(s), provided that: (a) we are properly notified and consent to return of the item(s) in question:(b) the item(s)
is / are returned with proof of purchase date; and (c) it is found upon inspection by us that the item(s) is / are defective
as noted above. This warranty does not cover labor costs, consequential damages, nor does it apply to any item(s) that
have been improperly installed, overloaded, altered, or otherwise abused by the customer, its agent(s) or employee(s).
Finishes are specially excluded from the terms of this warranty since they are subject to environmental maintenance
deemed beyond our control. Other than the described obligation, we assume no further liability with respect to the sale
or use of our products.We make no warranty, express or implied, and disclaim any warranty of merchantability or fitness
for a particular purpose.
1x
2x
Function and Operation
TURNING LIGHTS ON, OFF
Wave hand under 4 inches of
sensor once to turn light on or off.
LOCK / UNLOCK LIGHT
Wave hand under 4 inches of sensor
within 0. 5 seconds twice to lock or
unlock sensor.
NOTE: Dimming ranges from 100%
to 5% brightness.
DIMMING LIGHTS
Hold hand under 4 inches of sensor
to adjust brightness.
ON-OFF
LOCK-UNLOCK
DIMMING
Spare Parts List:
PC Diffuser X1
9863AC
Acrylic Cover X1
9867AC
Lock Ring X1
7151LR
Driver
7153DD
The following parts are available for re-order if damaged or missing.
