Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 1 Vax careline 0870 6061248 Vax model number: VZL-702U www.vax.co.uk instruction manual Bagless cylinder Please read carefully before using this cleaner. Always fully extend the mains cable before use. Retain for future reference.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 2 www.vax.co.uk 1. Diagram 3 4 2 5 6 7 8 9 1 10 11 15 13 16 12 14 Fig.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 3 Vax Careline 0870 606 1248 2. Safety Information 15. Do not vacuum up hard or sharp objects such as glass, nails, screws, coins, etc. For Household Use Only 16. Do not use without the filters in place. When using the vacuum cleaner, basic safety precautions should always be observed, including the following: 17. Take extra care when vacuuming on stairs. 1. Only use the vacuum cleaner indoors on dry surfaces. 19.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 4 www.vax.co.uk ! 3.! How to Assemble 4. How to Operate ! IMPORTANT: Always unplug the vacuum cleaner from the electrical outlet before assembling or removing the accessories. Cord Release ! 1. Insert the flexible hose (Fig.3/1) into the inlet on the main body of the vacuum cleaner. Making sure the projected parts on the hose are aligned. Turn the hose to the right until it clicks into lock position. Fully unwind the power cord.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 5 Vax Careline 0870 606 1248 5. Accessories 1. 2. The accessories can be attached directly to the handle by removing the telescopic tubes and pushing in the desired accessory. The accessories can also be attached to the telescopic extension tube for extra reach. Remove the combination floor head and push on the desired accessory. 6.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 6 www.vax.co.uk Cleaning the pre-motor filter ! 7.! Cleaning Blockages ! WARNING: To reduce the risk of electric shock, the power cord must be disconnected before performing maintenance/troubleshooting checks. NOTE: This is located underneath the dirt container bin. 1. Release the pre-motor filter cover by pulling on the tab. 2. Lift out the filter unit and separate the filter and case. 1. 3.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 7 Vax Careline 0870 606 1248 Switch the vacuum cleaner off and disconnect the power ! plug from the electrical outlet. 8.! Storage Lay the TurboBrush floor head on a flat surface and turn ! over to expose the brushbar. Using a pair of scissors, cut through any threads or hairs caught by the brushbar that have wrapped around the guides (Fig.7/3).
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 8 www.vax.co.uk ! 9.! Troubleshooting ! WARNING: To reduce the risk of personal injury, unplug the vacuum cleaner before performing maintenance/troubleshooting checks. ! PROBLEM: Vacuum cleaner won't run Cause: Not properly plugged into electrical outlet. Solution: Plug in securely. Cause: No electricity in the electrical outlet. Solution: Check fuse or breaker. Cause: On/off switch not turned on. Solution: Push on/off switch to ‘on’.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 9 Vax Careline 0870 606 1248 11. Technical Specification Voltage: 220 - 240 Wattage: 1400W Capacity: 1.1 litres approx Filters: Cyclone separator – wipe clean Pre-motor filter – washable Post-motor filter – washable Cord Length: 8m (approx) Weight: 8.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 10 www.vax.co.uk This page has been left intentionally blank.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 11 Vax Careline 0870 606 1248 This page has been left intentionally blank.
Vax VZL-702U User Guide.qxd 27/9/07 15:59 Page 12 EEC STATEMENT OF COMPLIANCE Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the VZL-702U Ultima cylinder range is manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive EMC: 2004/108/EC Electromagnetic Compatibility Directive Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
