VAX/VAXserver 4000-300, -400, and -500 Conversion
5.5 Installing the Kit
9. Place the new logo model label (P/N 36-33152-XX) over the existing label
on the fan tray on the front of the chassis as shown in Figure 5–1.
10. Attach the new serial and conversion labels as shown in Figure 5–2.
Figure 5–2 Conversion Label Location
Existing
Serial Label
Conversion
Label
LJ-00575-TI0
Product Conversion Label
From:
To:
By: Date:
36-15846-01-C1
A305
Model
SN
V
A
Hz
W
Made in U.S.A.
Fabrique aux Etats-Unis
708A
Listed
E.O.P. Equip.
220-240
8.0
50-60
850
Series BA400 CPU MOD KA660
FTZ C-250/89
This device complies with Part 15 of FCC Rules Operation is suspect to the following two conditions
(1) This device may not cause harmful intereference and,
(2) This device must accept any intereference received including intereference that may cause
undesired operation.
DOC Canada CSA DOC Canada CSA
VCCI 1
116A
5–6 VAX/VAXserver 4000-300, -400, and -500 Conversion
