VAX/VAXserver 4000-300, -400, and -500 Conversion
5.5 Installing the Kit
Figure 5–1 CPU Label Location
Baud
300___________0
600___________1
1200__________2
2400__________3
4800__________4
9600__________5
19200_________6
38400_________7
Bus 1
Bus 0
Y
X
Console Module
LJ-00574-TI0
L400X
-300/600
L4000
-AA
36-33152-12
36-33152-12
36-33152-12
LJ-02316-TI0
8. Turn on the power to the system and expander boxes if any, and run
diagnostics to verify system operation.
