Technical data

VAXserver 4000-200 Conversion
4.4 Installing the Kit
16. Place the new serial label over the existing serial label as shown in
Figure 4–4.
17. Attach the conversion label as shown in Figure 4–4.
Figure 4–4 Conversion and Serial Label Locations
Existing
Serial Label
Conversion
Label
LJ-00575-TI0
Product Conversion Label
From:
To:
By: Date:
36-15846-01-C1
A305
Model
SN
V
A
Hz
W
Made in U.S.A.
Fabrique aux Etats-Unis
708A
Listed
E.O.P. Equip.
220-240
8.0
50-60
850
Series BA400 CPU MOD KA660
FTZ C-250/89
This device complies with Part 15 of FCC Rules Operation is suspect to the following two conditions
(1) This device may not cause harmful intereference and,
(2) This device must accept any intereference received including intereference that may cause
undesired operation.
DOC Canada CSA DOC Canada CSA
VCCI 1
116A
18. Remove the old medallion and color strip (BA430 only) by using a flat-blade
screwdriver to lift it off the front panel.
VAXserver 4000-200 Conversion 4–7
