VAXserver/MicroVAX 3600/3900 Conversion
3.4 Installing the Kit
25. Add the JTT label, P/N 36-33180-18, to the BA213 front panel as shown in
Figure 1–6 for a rack-mountable system.
26. Attach the conversion label as shown in Figure 3–5.
27. Remove the old medallion using a flat-blade screwdriver to lift it off the
cabinet door.
28. Attach the new medallion as shown in Figure 3–6.
Figure 3–6 Medallion Location
MLO-002621
V
AX 4000-200
LJ-00536-TI0
3–10 VAXserver/MicroVAX 3600/3900 Conversion
