VAXserver/MicroVAX 3600/3900 Conversion
3.4 Installing the Kit
4. Remove the console cable as shown in Figure 3–2.
Caution
Wear the antistatic wrist strap and use the antistatic mat when
working with modules.
Figure 3–2 Removing CPU I/O Panel Console Cable
LJ-00579-TI0
Console
Cable
Locking Tab
Squeeze Locking Tab
and Pull From Jack
VAXserver/MicroVAX 3600/3900 Conversion 3–5
