VAXserver/MicroVAX 3600/3900

Conversion

This chapter describes how to convert from a VAXserver 3600/3900 system to a

VAXserver 4000-200 system and from a MicroVAX 3600/3900 system to a VAX

4000-200 system using a 660XR-XX conversion kit.

Note

VAXserver/MicroVAX 3600 and VAXserver/MicroVAX 3900 systems are

cabinet systems.

Caution

The MS650-AA memory module will not function with a KA660-XX

CPU module. When a KA650 or KA655 CPU module is removed and

the system is converted to a KA660-XX system, do the following:

1. Install an MS650-BA (16-Mbyte) memory or MS650-BB (8-Mbyte)

memory module.

2. Remove the H3600 CPU I/O panel and install the H3602 I/O panel.

The H3602 panel is included in the conversion kit.

VAXserver/MicroVAX 3600/3900 Conversion 3–1
